Clarysynt Mesh Pleated Cartridge Filters Manufacturer and Suppliers

These filter elements are produced from two types of metallic wire mesh: cylindrical wire mesh and pleated wire mesh. Depending on the types of particulates to be dealt with, we help you choose the right solution out of the two variants. As compared to polymeric pleated filters, the pleated wire mesh filters offer higher temperature resistance and higher flow rate with low differential pressure.

Features and Benefits

They are available in different grades of stainless steel.
Good permeability.
Our filters undergo exhaustive testing for porosity and mechanical strength.
Broad range of pore sizes.
High tensile strength.

Applications

Chemical/Petrochemical Filtration
Pharmaceutical
Food and Beverages
Refinery
Power generation
Electronics
Textile

Specifications

Materials
Filter Media/Support/Hardware
Stainless Steel (304, 304L, 316, 316L), Inconel®, Hastelloy®, Monel®, Others on request.
O-ring
Silicon , Viton*, Buna-N, EPDM, PTFE
Retention rating
0.5, 1, 2, 5, 10, 20, 50, 100 and 200 μm
Filter Media Type
Woven Wire Mesh
Filter Element Design
Pleated, Wrapped (Cylindrical)
Dimensions (nominal)
Length
10”, 20”, 30”, 40”, 50” (Others on request)
Diameter
Standard 2.5 inch (65 mm) (Others on request)
End Connection Type
DOE, SOE (222/Fin, 226/Fin, 222/Flat, 226/Flat), Thread (M20, M30, M40, NPT, BSP, BSPT) (Others on request)
Maximum operating conditions
Maximum forward operating pressure
1.5 MPa (15 bar) to 2.5 MPa (25 bar)
Maximum reverse differential pressure
0.3 MPa (3 bar) to 0.9 MPa (9 bar)
Maximum operating temperature
From -192oC to 350°C (seal M.O.C dependant)
